2017 SCM K800 Edgebander

Manufacturer: SCM Brand: SCM Model: T-FR2
Out of stock
$69,000.00 USD

Freight is not included in the machine price. iBiD Machinery will quote freight separately through our machinery freight broker.

How can iBiD help with this machine?

Questions about condition, specifications, loading, or fit? Ask iBiD directly, find a similar machine, or research the model.

Prefer to talk?

Call us about this machine’s condition, specifications, or freight.

Call iBiD · (678) 925-3556
Find a similar machine Sell one like this
Research & buying resources
Research this make & model Read the buying guide Research sold history

Your contact details are sent privately to iBiD and are not shown on the product page.

SCM K 800

 Many key features from larger machines are standard on the K800. A quick-change glue pot, electronic positioning of the top pressure beam, a fully programmable color controller, premilling and corner rounding.



The following are what is on the machine for sale.

  • ORION 110 CONTROL SYSTEM –Basic and intuitive for error-free machining. Memory capacity with up to 60 working programs.
  • STARTOUCH CONTROL SYSTEM -Intuitive and easy to use thanks to its customised graphics and one touch mode.
  • “iGLUE” KIT–Optimum finishing including delicate panels.
  • RT-E PANEL EDGE TRIMMING GROUP– Provides a perfect surface for gluing the edge.
  • AAR ANTI-ADHESIVE GROUP – It ensures the highest finishing quality by preventing the glue sticking to the upper and lower panel surfaces.
  • K/SEL END CUTTING GROUP – The best finishing quality thanks to the motors sliding on two independent guides.
  • RS/K IN-LINE TRIMMING GROUP – For the trimming of a solid wood edging or the removal of the exceeding edge thus providing the following chamfering operation.
  • RI/800 TRIMMING GROUP – The very best finishing quality with the rotating front and vertical copying discs. Rapid machine changeover between thin, radius and solid wood edges with the 2 and 3 pneumatic positions kit.
  • 2 MOTORS ROUND GROUP – Perfect rounding and trimming of straight, chamfered and post formed panels at 16 m/min.
  • RAS/1000 EDGE SCRAPING GROUP – Rapid and easy work changeover of the radius edge thanks to the substitution of the cutter-head, complete with rotating copying discs.
  • RCL GLUE SCRAPING GROUP – Eliminates any excess glue on the panel surface.
  • SPN BRUSHING GROUP – Allows panel cleaning and polishing.

Product Description:

Machine Location State:

Machine Location City:

Year: 2017

Make: SCM

Model: T-FR2

Serial No: A/120366

Phase/Voltage: ~3 / 230 Voltage/ 74A/ 60Hz

Condition: Excellent

Any Known Issues:

In Production:

Software transfers with machine:

Access to Forklift for Loading:

Loading Fee:

Shipping Dimensions: Will Provide For Shipping Quotes

Shipping Weight: Approx 5800 Pounds

Shipping Brackets Available:
