Description: Laguna Smartshop Maker CNC SS-M2 4x8' Router

BANK REPO MACHINE!

Table-W: 4 feet
Table-L: 8 feet
Power: 12 horsepower
RPM: 5,000 - 24,000
Spindle Type: Air-Cooled Italian-Made 5.5HP Hiteco Spindle
# Axis: 3
X: 97 inches
Y: 49 inches
Z: 7 inches
Z-Clearance: 12 inches
Z Travel: 13 inches
CNC Control: yes
Tool Changing System: 8 Position Automatic
Vacuum Table: 4 to 6 Zone
Rapid Travel: 600 IPM
Rapid Speed: 350 IPM
Drive System: Planetary Gear Box
Features:: Heavy-Duty One-Piece All-Steel Frame, Allows Expansion For 4th Axis Turner, 6HP Spindle 8 Position Automatic Tool Changing System 12″ Z-Clearance 13″ Z Travel Up To 600 IPM Rapid Speed Vacuum Table (4 Zone For 4′ x 8′ & 6 Zone For 5′ x 10′) Nema 34 Stepper Drive Motor Syntec Control System
Dimensions: 132" x 87" x 72"
Weight: 2200 pounds

Laguna Smartshop Maker CNC SS-M2 4x8' Router equipped with Heavy-Duty One-Piece All-Steel Frame, Allows Expansion For 4th Axis Turner, 6HP Spindle 8 Position Automatic Tool Changing System 12″ Z-Clearance 13″ Z Travel Up To 600 IPM Rapid Speed Vacuum Table (4 Zone For 4′ x 8′ & 6 Zone For 5′ x 10′) Nema 34 Stepper Drive Motor Syntec Control System

*Information displayed has been gathered from machine owner, internet searches and other sources. Information is believed to be correct, but not guaranteed. All buyers should verify this information independently and/or have the machine inspected for accuracy prior to purchase*

Product Description: Laguna Smartshop Maker CNC SS-M2 4x8' Router - Florida

Machine Location State: Florida

Machine Location City:

Year:

Make: Laguna

Model: Smartshop Maker CNC SS-M2

Serial No:

Phase/Voltage:

Condition:

Any Known Issues:

In Production:

Software Transfer:

Access to Forklift for Loading:

Loading Fee:

Shipping Dimensions:

Shipping Weight:

Shipping Brackets Available:
