• US NORMS

• LANGUAGE: ENGLISH

• VOLTAGE: 480V

• FREQUENCY: 60 HZ

• FIXED TABLE (CONSTANT PASS-LINE) AT 900 MM FROM THE FLOOR LEVEL

• BL-32 READING BAR FOR “EPICS” ELECTRONIC SECTIONAL PAD (PITCH: 32 MM)

• SINGLE PHASE TRANSFORMER

• ABRASIVE BELT WIDTH: 1370 MM

• ABRASIVE BELT LENGTH: 2620 MM

1ST POSITION

• 250 MM DIAMETER DRUM WITH 90 SH RUBBER COATING

• 22 KW MOTOR

• ABRASIVE BELT CLEANING BLOWER

2ND POSITION

• 250 MM DIAMETER DRUM WITH 65 SH RUBBER COATING

• 18.5 KW MOTOR

• ABRASIVE BELT CLEANING BLOWER

3RD POSITION

• COMBI UNIT WITH:

• 140 MM DIAMETER DRUM WITH 40SH RUBBER COATING

• “EPICS” ELECTRONIC SECTIONAL PAD (PITCH: 32 MM)

• MANAGEMENT OF “EPICS” PAD WORKING PRESSURE THROUGH CONTROL PANEL

• ABRASIVE BELT CLEANING BLOWER

• INVERTER CONTROLLED 15 KW MOTOR

• TURBO BLOWERS FOR WORKPIECE CLEANING AT THE MACHINE OUTEED

• 50SH RUBBER FEED MAT

• INVERTER CONTROLLED 2.2 KW FEED MAT MOTOR

• SUPPORT TABLE AT THE MACHINE INFEED WITH 5 IDLE ROLLERS

• SUPPORT TABLE AT THE MACHINE OUTFEED WITH 5 IDLE
