Voorwood L 79D (H) End Finisher and Foiler - Michigan

Voorwood L79D(H) end finisher and foiler located in Michigan. The L79 platform is designed to cut MDF mouldings to length, sand the ends and apply a transfer finish in a production-oriented one-pass process. Call iBiD Machinery at (678) 925-3556 for current condition and machine-specific setup details.

Process overview

• Precision cut-to-length operation for mouldings/components
• End sanding following the cut cycle
• Transfer-finish / foil application using a heated applicator wheel
• Automatic heat control
• Hopper-fed production configuration
• Designed to minimize setup time for repetitive louver/moulding end finishing

Inspecting this Voorwood L79D(H) end finisher

Confirm the exact L79D(H) workpiece length/section capacity, saw and sanding motor ratings, foil width/material compatibility, heater controls, hopper/feed configuration, electrical/pneumatic requirements and tooling included.

*Specifications are provided to the best of iBiD Machinery's knowledge using seller-provided information, available manufacturer information and other credible technical references. Actual machine configuration, options, dimensions and capabilities may vary by year, serial number and installed equipment. Buyer should independently confirm all specifications and inspect the machine before purchase.

Product Description: The Voorwood L79 End Finisher is designed to precisely cut MDF mouldings to length, then sand both ends. Next, to complete the one-pass process, an applicator wheel with automatic heat control applies the transfer finish. A louver end foiler is a production-oriented machine designed for reliability and operator convenience using a hopper feeder. Set-up time is kept to a minimum by many special Voorwood features.

The L79 End Finisher positive feed system ensures accurate finishing. As parts are fed past the station, they are clamped securely between the bottom lugged chain and the top hold-down belt. The frame is made of a welded rigid steel construction with specially selected alloy steels that are used throughout. Rotating components are dynamically balanced and electronically tested for vibration after the final assembly.

The L79 End Finisher has an applicator wheel with automatic heat control that applies the transfer foil to louver ends. An end finisher is a production-oriented machine designed for reliability and operator convenience. The carrier film rewinds with automatic tension control. The stripper-rollers provide for precision trimming foil on the edges.

Accommodates a maximum part length from 6″–80″
Accommodates a part width up to 8.50″
Endless belt hold-down and bottom chain with pop-up lugs 3″ spacing
Fully adjustable bottom scoring precisely cuts MDF louver parts to length
Sands both ends of parts, preparing the surface for finishing
Applicator wheel with automatic heat control
Hopper feeder (option)
Foils a 1.875″ face width

Machine Location State: Grand Rapids

Machine Location City: Michigan

Year:

Make: Voorwood

Model: L79 D (H)

Serial No: 10352

Phase/Voltage: 3

Condition: Excellent Condition

Any Known Issues: No

In Production: Just taken out of production

Software transfers with machine: Finishing

Access to Forklift for Loading: Yes

Loading Fee: No

Shipping Dimensions: Will provide

Shipping Weight: Will provide

Shipping Brackets Available: N/A
